Applications
Overview
The Applications panel lists all applications available in CAST Imaging and provides various technical options, including:
- manage domains
- manage CAST Imaging Core upgrade
- manage data source for source code viewing for imported applications
- manage advisor for viewer
- manage backups
- manage nodes
- manage log debug options
Column headings
| Heading | Description |
|---|---|
| Application name | Display name for the application. |
| Domain | The domain the application belongs to (if any). See also Working with domains. |
| Created by | The user that created or imported the application. |
| Core version | The CAST Imaging Core release used to analyze the application. Where no version number is visible, the application has been imported in results form instead. |
| Core upgrade available | If a release number is listed, this indicates that the CAST Imaging Core release used to analyze the application is out-of-date and that a new release is available. See Using the CAST Imaging Core upgrade option. |
| Import version | Indicates the internal engine release number used to generate the results. |
| Import duration | Indicates the length of time required to generate the results. |
| Actions | Contextual menu containing various options. See Actions. |
Icons
The icons available above the list of applications indicate the following:
| Icon | Description |
|---|---|
 |
Delete the application. |
 |
Assign the application to a specific domain. See Working with domains. |
 |
When active, allows you upgrade CAST Imaging Core (used to analyze the application) to a new release. See Using the CAST Imaging Core upgrade option. |
 |
Allows you to upgrade the Advisor feature to take advantage of improved rules. |
 |
When blue, this icon indicates that a result generation or application result import job is currently in progress. Clicking the icon will reveal the job in progress and any that might be queued: |
Actions
Icons
Icons will indicate both:
- in-progress jobs
- completed jobs (a flag coloured depending on the job outcome).
Clicking any of the icons will display the current on-going job logs, or the most recent if the job is completed.
Contextual menu
| Menu option | Description |
|---|---|
| View details | |
| View data source | Add a connection to a CAST Storage Service/PostgreSQL instance specifically to view source code for applications that have been imported. See Managing data source configuration. |
| Change domain | Assign the application to a specific domain. See Working with domains. |
| Upgrade application | When active, allows you upgrade CAST Imaging Core (used to analyze the application) to a new release. See Using the CAST Imaging Core upgrade option. |
| Optimize | Run various database optimization options for the schemas related to the current application (*_MNGT, *_LOCAL, *_CENTRAL, general_measure). These options are also available in the Global Configuration administration options, see Optimization. |
| Download import logs | Downloads all logs associated with the process of generating results post analysis. A file called “logs” is downloaded which can be opened with a text editor. |
| Rename / Delete | Rename or Delete an existing application. |
